>> 產品介紹
1. Feature:
(1) Proprietary LED module packaging design of thermal management for lumen maintenance.
(2) High brightness with good efficiency and reliability.
(3) Make no image stacking.
(4) High efficient and stable power control unit with over voltage and short circuit protection.
（5）Low-depth aluminum alloy housing with elegant design.
（6）Low heat, no UV or IR radiation.
2. Specifications:
(1) Light source: multichips LED module.
(2) Input voltage for controller: 96 - 260VAC, 47 - 63Hz.
(3) Constant current for operation: 300mA @ 32V full load condition.
(4) LED Module Power consumption: 10W.
(5) Color temperature / Light output luminous flux:
Warm White:650 lum
Cool White:700 lum
(6) Weight: 0.4 Kg.
(7) Insert hole: 150 mm dia
(8) Beam angle: 120 degree.
(9) Service life: 20,000 hours, Lumen maintain70% at 20K hours.
(10) Ambient temperature: -20 to 40 degree C.
Temperature of housing surface: 40 degree C below.
|
|
 |
|
|
|
|
|
|
|
